TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

Product Categories
Beijing GYG Industry Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

  • 1
  • 2

Brand Name : GYG

Model Number : GX-200

Place of Origin : China

MOQ : 1SET

Price : 50-200 USD/SET

Payment Terms : Western Union, MoneyGram, T/T

Supply Ability : 76000Sets /Year

Delivery Time : 3-5 working days

Packaging Details : Standard Packing,Packed in carton or as per client's request

Sheave diameter : Φ200 mm ; Φ240 mm

Wire rope diameter : Φ6 mm; Φ8 mm

Shipping : Sea/Air/DHL/Fedex

Port : Beijing/ Shanghai/ Tianjin

Contact Now

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

Function of tension device

Keep the speed limiting wire rope tensified to ensure that the wire rope rotates in line with the rotation of the

rope wheel and that the speed limiter can provide the necessary brake lift

PERFORMANCE PARAMETERS:

Sheave diameter

 Φ200mm; Φ240mm

wire rope diameter

 Φ6 mm; Φ8 mm

Weighe type

 Barite(High density of ore),cast iron

Installation position

 elevator pit guide rail side

Structure form

 swing rod

The above parameters according to the corresponding specific speed limiter technology parameters matching

Category Rope wheel diameter Diameter of wire rope A B Quality of balancing Applicable state
A01

Φ200

Φ6

315-385

20-80

 12kg ≤50m
A02 Φ6 16kg 50-100
A03

Φ240

 Φ6,Φ8 12kg ≤50m
A04 Φ6,Φ8 16kg 50-100
A05 Φ8 24kg 50-100

Quality of balancing Weight material E F G
6kg Cast iron 285 45 85
8kg Cast iron 250 50 105
8kg Barite 265 70 130
12kg Barite 265 85 165

1.The above parameters are suggested, please calculate according to actual state.

2. Weight parameters listed in the tale should be confirmed according to actual match.

3. When choosing 300 rope wheel ,please contact us for technical parameters.


PRODUCTS SHOW:

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MMTENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

PAYMENT&SHIPPING

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

CERTIFICATIONS:

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM

Exhibition Show:

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM


China TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM factory

TENSION DEVICE GX-200 ELEVATOR SAFETY PARTS, SHEAVE DIAMETER 200MM/240MM Images
